The R75 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P75 Series

Key Specifications:

Connection Type: Wire-wrap

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 1.91mm (75mil)

Mounting Hole Diameter: 1.4mm

Current Rating: 2A continuous

The R75 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P75 Series

Key Specifications:

Connection Type: Solder Cup

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 1.91mm (75mil)

Mounting Hole Diameter: 1.4mm

Current Rating: 2A continuous

The R50 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P50 Series

Key Specifications:

Connection Type: Crimp

Collar Height: 5mm

Minimum Center-to-Center Pitch: 1.27mm (50mil)

Mounting Hole Diameter: 1mm

Current Rating: 2A continuous

The R50 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P50 Series

Key Specifications:

Connection Type: Wired

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 1.27mm (50mil)

Mounting Hole Diameter: 1mm

Current Rating: 2A continuous

The R50 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P50 Series

Key Specifications:

Connection Type: Solder Cup

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 1.27mm (50mil)

Mounting Hole Diameter: 1mm

Current Rating: 2A continuous

The R50 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P50 Series

Key Specifications:

Connection Type: Crimp

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 1.27mm (50mil)

Mounting Hole Diameter: 1mm

Current Rating: 2A continuous

The R100 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P100 Series

Key Specifications:

Connection Type: Wire-wrap

Collar Height: 7.5mm

Minimum Center-to-Center Pitch: 2.54mm (100mil)

Mounting Hole Diameter: 1.75mm

Current Rating: 2A continuous

The R100 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P100 Series

Key Specifications:

Connection Type: Wire-wrap

Collar Height: 5mm

Minimum Center-to-Center Pitch: 2.54mm (100mil)

Mounting Hole Diameter: 1.75mm

Current Rating: 2A continuous

The R100 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P100 Series

Key Specifications:

Connection Type: Wire-Wrap

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 2.54mm (100mil)

Mounting Hole Diameter: 1.75mm

Current Rating: 2A continuous

The R100 series, part of the Generic Receptacles product group, offers a value line receptacle solution designed for reliability and cost efficient performance. This series of receptacles is used in our Development series of fixtures.

Compatible Test Probes: P100 Series

Key Specifications:

Connection Type: Solder Cup

Collar Height: 2.5mm

Minimum Center-to-Center Pitch: 2.54mm (100mil)

Mounting Hole Diameter: 1.75mm

Current Rating: 2A continuous

Elevate your PCBA testing with the FixturFab FixturCtrl, featuring

6 Programmable USB2.0 Ports: Independent control of power and data connections, ideal for automated device management during tests.

Fixture Switch/Cycle Counter Input: Compatible with Ingun Inductive Switches (MA2xxx and MA3xxx series fixture bases), with cycle counting for maintenance tracking.

Dual I2C Expansion Ports: Easy integration of Qwiic I2C-based devices from Sparkfun and Adafruit, quickly enhance your testing capabilities.

Digital IO Expansion Port: Customize your fixture base with additional interfaces like buttons and LEDs to improve user interaction.

Compact and versatile, the FixturCtrl is the perfect tool for streamlined and efficient PCBA testing.

The PQ50 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ50 Series

Tip Type: Spear
Minimum Center-to-Center Pitch: 1.27mm (50mil)
Current Rating: 3A continuous, <60mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 120gf (4oz)
Material: 3CuBe with Gold Plating

The PQ50 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ50 Series

Tip Type: Cup
Minimum Center-to-Center Pitch: 1.27mm (50mil)
Current Rating: 3A continuous, <60mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 120gf (4oz)
Material: 3CuBe with Gold Plating

The PQ75 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ75 Series

Tip Type: Spear
Minimum Center-to-Center Pitch: 1.9mm (75mil)
Current Rating: 3A continuous, <40mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 112gf (4oz)
Material: 3CuBe with Gold Plating

The PQ75 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ75 Series

Tip Type: Cup
Minimum Center-to-Center Pitch: 1.9mm (75mil)
Current Rating: 3A continuous, <40mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 112gf (4oz)
Material: 3CuBe with Gold Plating

The PQ100 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ100 Series

Tip Type: Needle
Minimum Center-to-Center Pitch: 2.54mm (100mil)
Current Rating: 3A continuous, <30mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 120gf (4oz)
Material: 3CuBe with Gold Plating

The PQ100 series of probes is used in all of our DEV260 Pro fixtures.

Compatible Receptacles: Centalic PQ100 Series

Tip Type: Cup
Minimum Center-to-Center Pitch: 2.54mm (100mil)
Current Rating: 3A continuous, <30mOhm Resistance
Full Stroke: 6.35mm
Rated Stroke: 4.30mm
Spring Force: 203gf (7.2oz)
Material: 3CuBe with Gold Plating

The RQ50 series, part of the Centalic RQ product group, offers an robust receptacle solution designed for reliability and performance. These receptacles feature a press-in version with a gold surface area, ensuring high-quality electrical connections. This series of receptacles is used in all of our DEV260 Pro fixtures.

Compatible Test Probes: Centalic PQ-50 Series

Key Specifications:

Connection Type: Solder Cup

Minimum Center-to-Center Pitch: 1.27mm (50mil)

Mounting Hole Diameter: 1mm

Current Rating: 3A continuous, <60mOhm Resistance

Material: 3CuBe with Gold Plating

The RQ75 series, part of the Centalic RQ product group, offers an robust receptacle solution designed for reliability and performance. These receptacles feature a press-in version with a gold surface area, ensuring high-quality electrical connections. This series of receptacles is used in all of our DEV260 Pro fixtures.

Compatible Test Probes: Centalic PQ-75 Series

Key Specifications:

Connection Type: Solder Cup

Minimum Center-to-Center Pitch: 1.91mm (75mil)

Mounting Hole Diameter: 1.35mm

Current Rating: 3A continuous, <40mOhm Resistance

Material: 3CuBe with Gold Plating

The RQ100 series, part of the Centalic RQ product group, offers an robust receptacle solution designed for reliability and performance. These receptacles feature a press-in version with a gold surface area, ensuring high-quality electrical connections. This series of receptacles is used in all of our DEV260 Pro fixtures.

Compatible Test Probes: Centalic PQ-100 Series

Key Specifications:

Connection Type: Solder Cup

Minimum Center-to-Center Pitch: 2.54mm (100mil)

Mounting Hole Diameter: 1.75mm

Current Rating: 3A continuous, <30mOhm Resistance

Material: 3CuBe with Gold Plating
