The INGUN KS-075 47 G (INGUN item KS-07547G) is a press-in receptacle for the 75 mil (1.91 mm) grid with a wire-wrap tail and a press ring. It is pressed into the fixture's probe plate and the spring probe plugs into it, so probes can be exchanged during servicing without touching the harness.
This is the long, wrap-terminated end of the KS-075 range: 40 mm overall against 30 mm for the solder-cup versions, with a 10 mm wire-wrap post. Choose it when the fixture is wire-wrapped rather than soldered, and when vacuum integrity matters — this variant is vacuum-tight, where the 30-series solder-cup parts are not.
Total length 40 mm (1.57 in), outer diameter 1.32 mm (.051 in)
Collar diameter 1.47 mm, collar height 7.6 mm; with press ring
Mounting hole 1.31 – 1.33 mm in FR4 (1.39 – 1.40 mm with press ring)
Wire-wrap termination, post length 10 mm; gold surface
