The INGUN KS-075 30 E05 (INGUN item KS-07530E05) is a press-in receptacle for the 75 mil (1.91 mm) grid with a press ring. The receptacle stays in the probe plate and the spring probe plugs into it, so probes are exchanged without any wiring work.
It shares the 30 mm body and press ring of the KS-075 30 G but uses a 2 mm collar instead of 7.6 mm. That is the variant to reach for when the plate stack-up leaves little room above the probe plate and a tall collar would foul a spacer or guide plate, while still keeping the repeatable press depth the ring provides.
In Studio this receptacle is paired with the INGUN GKS-075 probe family and with Centalic PE75 probes.
Total length 30 mm (1.18 in), outer diameter 1.32 mm (.051 in)
Collar diameter 1.47 mm, collar height 2 mm; with press ring
Mounting hole 1.31 – 1.33 mm in FR4 (1.39 – 1.40 mm with press ring)
