Ingun GKS-135 360 090 A 2000, Crown Tip, 100mil

The INGUN GKS-135 360 090 A 2000 (INGUN item GKS-135-0154) is a bead probe: a long-stroke spring test probe whose 60 head is serrated and shaped for small-grid targets, intended for contacting solder beads and other very small deposited features rather than conventional test pads.

It runs on the 2.54 mm (100 mil) grid in a KS-100 receptacle and shares the GKS-135 long-stroke body — 9.3 mm working stroke — so it can be mixed into a dual-stage ICT/FCT fixture alongside standard GKS-135 probes. The CuBe head carries a higher 8 A rating than the steel-tipped needle and crown variants of the same series.

• Tip style 60, serrated, small grid; CuBe with gold finish
• Tip diameter 0.9 mm (.035 in), barrel diameter 1.37 mm (.053 in)
• Grid 2.54 mm (100 mil); total length 38.7 mm (1.52 in)
• Working stroke 9.3 mm (.366 in), maximum stroke 11.5 mm (.452 in)
• Spring force 2 N at working stroke (pre-load 0.21 N)
• Rated current 8 A; typical resistance 30 mΩ
• Plug-in mounting in a KS-100 receptacle; quick-exchange system
• Operating range −40 °C to 80 °C; RoHS-compliant
