Ingun GKS-135 225 130 A 1500, Crown Tip, 100mil

The INGUN GKS-135 225 130 A 1500 (INGUN item GKS-135-0140) is a long-stroke test probe on the 2.54 mm (100 mil) grid, offering 9.3 mm of working stroke against the 4.3 mm of a standard GKS-100 while still using the ordinary KS-100 receptacle.

The 25 tip is a self-cleaning 6-point crown with a middle point, and that combination is specifically aimed at posts and pins: the surrounding crown captures and centres a round lead, while the centre point makes contact on the end face. Together with the long stroke it is the natural choice for contacting header pins, through-hole leads and connector posts of varying height, where a flat or chisel tip would slide off the top of the lead.

• 25 6-point crown with middle point, self-cleaning, ø1.3 mm (.051 in), steel, gold-plated
• 2.54 mm (100 mil) grid, barrel diameter 1.37 mm (.053 in), collar height 00
• Total length 38.7 mm (1.52 in)
• Working stroke 9.3 mm (.366 in), maximum stroke 11.5 mm (.452 in)
• Spring force 1.5 N (5.39 ozf) at working stroke; pre-load 0.23 N
• 5 A rated current, typical resistance 30 mΩ
• Contacts posts and pins; plug-in mounting in KS-100, quick-exchange
• Operating range −40 °C to +80 °C; RoHS-compliant
