Ingun GKS-100 319 300 A 1000 Q15 Test Probe, Cupped Tip, 100mil

The INGUN GKS-100 319 300 A 1000 Q15 (INGUN item GKS-100-1994) is an interface-block probe: a GKS-100 body used not against a PCB but in the interface between a tester and a fixture, where it has to find and hold a mating pin reliably over many docking cycles.

The 19 head is a slotted 90° inverse cone, self-cleaning, 3 mm across — a wide crater that captures and centres a post or pin, with the slot letting the head wipe as it seats. INGUN codes this variant "Q15": it is 1.8 mm longer than the standard GKS-100 and adds defined wobble clearance with a ball and centring feature, so the probe can take up the small misalignments an interface block sees at docking.

• Tip style 19, 90° inverse cone, slotted, self-cleaning; CuBe with gold finish
• Tip diameter 3 mm (.118 in), barrel diameter 1.37 mm (.053 in)
• Grid 2.54 mm (100 mil); total length 35.2 mm (1.38 in)
• Working stroke 4.3 mm, maximum stroke 6.35 mm; spring force 1 N at working stroke (pre-load 0.35 N)
• Rated current 5 A; typical resistance 20 mΩ
• Plug-in mounting in a KS-100 receptacle; quick-exchange system
• Operating range −40 °C to 80 °C; RoHS-compliant
