Acroname MTM-PM-1
Acroname MTM-PM-1
Software-Controlled DC Power Supply for Manufacturing & R&D Test
The Acroname MTM-PM-1 is a precision programmable power supply built for demanding test environments. Optimized for devices with LiPo batteries and high transient loads—like cellular radios (GSM, LTE, CDMA)—it delivers rock-solid power with exceptional load transient response. Exceeds 3GPP battery emulator specifications for cellular radio testing.
Key Specifications
Output Power
- Output voltage: 1.8V to 5.0V DC (50µV resolution)
- Continuous current: Up to 3A
- Output voltage precision: Better than 1%
- Current limit precision: 1%
Measurement
- Current measurement: 0 to 3.3A with 50µA resolution
- On-board temperature sensor at linear regulation stage
- Optional K-type thermocouple interface: -25°C to +400°C
- Analog current output (1V/A) for external monitoring
Load Performance
- Transient response: <1% droop at 28µs from 2A transient
- Kelvin sensing (4-wire) feedback for precision regulation
Power Topology
- Software-selectable: Fully linear or SMPS-to-linear operation
- Fully linear mode for RF-sensitive/noise-sensitive applications
- SMPS pre-conditioning mode for improved thermal efficiency
Input & Environmental
- Input voltage: 6.0V to 12.0V DC
- Operating temperature: 0°C to 70°C (no external cooling required)
- Automatic thermal failover or shutdown protection
Why Choose the MTM-PM-1?
Built for Battery-Powered Device Testing
Exceptional transient response handles the demanding current spikes from cellular radios and other battery-powered devices. Exceeds 3GPP battery emulator specifications—no compromises when testing wireless devices.
RF-Clean Power Option
Switch to fully linear mode for noise-sensitive RF testing. No switching noise to contaminate your measurements. When thermal headroom matters more, enable the SMPS pre-conditioning stage.
Precision Measurement Built In
Monitor output current with 50µA resolution. Track device and equipment temperatures with the on-board sensor or optional K-type thermocouple. Analog current output available for third-party data acquisition.
Production-Ready Durability
Part of Acroname's Manufacturing Test Module (MTM) series, ruggedized for CM and OEM environments worldwide. All pin interfaces include reverse polarity and overvoltage protection.
Flexible Integration
Connect directly to a host PC via USB, or network with other MTM modules over I2C. Program with the BrainStem API (C++, Python) or run standalone embedded programs.
Ideal Applications
- Cellular radio testing (GSM, UMTS, LTE, CDMA)
- Battery emulation for portable devices
- IoT and wearable device power testing
- RF-sensitive measurement environments
- Current profiling and power consumption analysis
- Automated functional test systems
What's in the Box
- MTM-PM-1 Module
Technical Resources
- BrainStem SDK (C++, Python) — free download from Acroname
- CAD files (STEP, IGES) available
- Detailed datasheet with full specifications
Manufacturer: Acroname Inc. (Boulder, CO, USA)
SKU: S65-MTM-PM-1
